PUR Wall Panel

Request a Call Back

    Description:

    PUR (Polyurethane) Wall Panels are insulated panels designed for high-performance thermal insulation and energy efficiency in wall applications. These panels consist of a rigid polyurethane foam core sandwiched between two layers of pre-painted or galvanized steel. PUR Wall Panels provide superior insulation, making them ideal for applications that require temperature control, such as cold storage, clean rooms, and industrial buildings. They are lightweight, durable, and offer excellent fire and moisture resistance.

    Item

    Details

    Material

    Pre-Painted Galvanized Steel (PPGI) / Aluminum

    Coating

    Zinc Coating / Polyester / PVDF Coated

    Core

    Rigid Polyurethane Foam (PUR)

    Thickness

    40 mm to 200 mm (Core thickness)

    Profile

    Flat or Micro-Ribbed Panel Profile

    Length

    Customizable (Up to 12 meters)

    Width

    Standard: 1,000 mm

    Standards

    ASTM C518, EN 14509, IS 14246

    Raw Materials:
    The PUR Wall Panels are manufactured using high-quality galvanized or aluminum steel sheets, bonded to a rigid polyurethane foam core. The foam core provides excellent thermal insulation while the steel or aluminum layers offer structural strength and resistance to external elements.

    RAL Colors Available:
    PUR Wall Panels come in various RAL colors to match project aesthetics and functional needs. Popular RAL colors include:

    • RAL 9002 – Grey White
    • RAL 5010 – Gentian Blue
    • RAL 3005 – Wine Red
    • RAL 9010 – Pure White

    Custom colors and finishes are available on request.

    Features:

    • Excellent thermal insulation due to the rigid PUR foam core.
    • Lightweight construction, reducing structural load.
    • Fire-resistant and moisture-resistant properties.
    • Long-lasting with minimal maintenance required.
    • Easy to install, reducing labor costs and project duration.

    Applications:
    PUR Wall Panels are widely used in applications requiring high insulation and temperature control. Typical applications include:

    • Cold storage facilities and refrigerated warehouses.
    • Clean rooms for pharmaceutical and food industries.
    • Industrial and commercial building walls.
    • Prefabricated modular buildings.
    • Temperature-controlled environments in food processing.
